Light Source
Light Source: 32 × 40W RGBW LEDs + 144 × 5W 3535 White LEDs
Fixture Color Temperature: RGBW: 6500K-7000K | White Light: 7000K-7500K
Lifespan: 50,000 hours
Optical System
Lens Angle: 40°
Control & Programming
Control: 4 touch buttons
Control Panel: LCD display
Control Protocol: DMX / Auto / RDM / Art-Net
Control Channels: 10CH / 17CH / 136CH / 139CH / 153CH
Software Upgrade: Upgradable via DMX connection
Electrical & Connectors
Input Voltage Range: AC100-240V ~ 50/60Hz
Power Consumption: 1300W
Power Connector: Waterproof "PowerPASS" Input/Output
Signal Input/Output: Waterproof 3-pin XLR "DataPASS"
Ethernet Input/Output: RJ45
Fixture Specifications
Dimensions: 510 × 92.5 × 440 mm (20.08 × 3.64 × 17.32 in)
Net Weight: 19 kg (41.88 lbs)
Additional Specifications
Protection Rating: IP65
Maximum Operating Ambient Temperature: 45°C
Minimum Operating Ambient Temperature: -10°C
