Power Parameters
Input Power: AC100-240V
Power Frequency: 50/60Hz
Power Consumption: 400W
LED Parameters
Light Source: 36 × 5W Amber LEDs
Auxiliary Lights: 324 × 1W RGBW LEDs
Average Lifespan: 50,000 hours
Dimming: 0-100% Linear Dimming
Strobe: 1-25Hz
Control & Features
Channel Modes: 6/16/193/1332/1336CH (upgradable via DMX)
Control Modes: DMX / Auto / Sound Control / Art-Net / Master-Slave
Display: LCD Screen
Features: 0-100% linear dimming, chase + strobe + text display + flowing water + color washing + pixel effects, individual pixel control
Connectors
Signal Input/Output: Waterproof 3-pin XLR socket, RJ-45 interface
Power Connector: Waterproof PowerCON input/output
General Specifications
Protection Rating: IP65
Operating Temperature Range: -30°C to 50°C
Housing Color: Black
Product Dimensions: 500 × 500 × 118 mm
Net Weight: 14.4 kg
