SPL-MHL-M420IP
SPL-MHL-M420IP
Detailed Introduction
Electrical Parameters:
- Input Power: AC100-240V
- Power Frequency: 50/60Hz
- Power Consumption: 570W
MHL Parameters:
- Light Source: 420W
- Lumen Value at 15m Distance: Lux
- Beam Angle: 1.5°
- Dimming: 0–100% Linear Dimming
- Strobe: 1S/25 (Built-in Multiple Strobe Effects)
Motor Scanning Parameters:
- Horizontal Scan: 540° (16-bit Precision)
- Vertical Scan: 270° (16-bit Precision)
Features:
- Patterns: 17 Patterns + 1 White Circle
- Colors: 14 Colors + 1 White Circle
- Prism Wheel 1: (8+8+8) + (8+16+24) + 6 Line Mirrors
- Prism Wheel 2: 8 + (8+16) + 6 Line Mirrors
- RGB Effect: Yes
- Focus: Adjustable
Control Methods:
- Channel Mode: 16CH
- Operating Modes: DMX / Auto / RDM
- Display Type: LCD Screen
Input/Output:
- DMX Connector: 1.2m 3×0.5mm Waterproof Daisy-chain Signal Cable
- Power Connector: 1.2m 3×2.5mm Waterproof Daisy-chain Power Cable
Other Parameters:
- Protection Rating: IP65
- Maximum Operating Ambient Temperature: 45°C
- Product Dimensions: mm
- Net Weight: 32.5kg
